SurgeX SX-DC-8-24-120 Smart AC DC Surge Protector 24V DC Output

Professional-Grade AC/DC Power Control in a Compact, Smart Package
The SurgeX SX-DC-8-24-120 SQUID Series is a next-generation smart surge protector and power management system that supports 120V or 240V AC input while simultaneously delivering regulated DC power for integrated AV, broadcast, and IT systems.

With 4 individually controlled AC outlets, dual DC output banks, USB charging, and a built-in 5V DC output, this unit consolidates multiple power functions into a single, compact form factor. Ideal for mounting behind displays or inside racks, the SX-DC-8-24-120 is a favorite among professional integrators.

Via Ethernet control, users can remotely reboot, power sequence, monitor voltage/frequency, and manage connected equipment. It supports modern network protocols including HTTPS, SNMPv3, LDAP, and 802.1x, making it enterprise-ready.

SurgeX’s patented Advanced Series Mode® protection ensures total defense without MOV-based failure points, handling up to 6,000V surges while delivering zero let-through energy. EMI/RFI filtering and COUVS shutdown guard sensitive equipment from noise and dangerous power anomalies.

Whether powering a digital signage array, AV control system, or networked automation hub, the SX-DC-8-24-120 offers smart power, safety, and stability — all in one.

Smart power management with surge protection for AC/DC systems
4 switched grounded AC receptacles (individually monitored)
2 DC output banks (each with 2 detachable connectors)
5V unswitched DC output + 2 USB-A charging ports
Wired Ethernet for remote reboot, sequencing, scheduling
Full power analytics: voltage, current, energy, temperature
Compatible with HTTP, HTTPS, SNMP v1/v3, 802.1x, NTP, LDAP
Onboard event logging and 30-day parameter memory
Compact mountable steel enclosure — only 1.75" depth
Supports 120V/15A or 240V/10A operation
Built-in EMI/RFI filtering and over/under-voltage shutdown
Software-enabled self-test with visual feedback
