Strong SM-CB-ART1-M Single Arm Tilt TV Wall Mount 24–55 Inch

Flexible Full-Motion Positioning for Medium-Size TVs

The Strong SM-CB-ART1-M Carbon Series is a single-arm articulating wall mount for 24–55" TVs weighing up to 100 lb. It is designed for rooms where you want more flexibility than a fixed or tilt-only mount, including the ability to pull the screen away from the wall, swivel it toward different seating positions, adjust tilt for glare control, and fine-tune the screen level after installation.

It works well in bedrooms, living rooms, offices, media rooms, kitchens, and other spaces where a medium-size display needs flexible positioning without the size of a dual-arm mount.

Key Specifications

• TV size: 24–55"
• Maximum load: 100 lb (45 kg)
• Extension: Up to 19"
• Retracted depth: Approximately 3.25"
• Swivel: Up to 180°
• Tilt: +15° / -5°
• Roll adjustment: ±5°
• VESA support: Up to 400 × 400 mm on supported patterns
• Certification: UL Certified
• Warranty: Limited Lifetime Warranty

Who Should Choose This Mount?

Choose the SM-CB-ART1-M if your compatible TV needs to extend away from the wall or turn toward different viewing positions. The articulating arm also makes it easier to reach HDMI, power, network, and other rear connections after installation.

If the TV will remain facing straight ahead and you do not need extension or swivel, a lower-profile fixed or tilt mount may be a simpler option. You can compare alternatives in our TV Wall Mounts collection or browse more Strong mounting solutions.

TV and VESA Compatibility

The 24–55" screen-size range is only one part of compatibility. Your TV must also weigh no more than 100 lb and use a supported mounting-hole pattern.

Strong currently lists support for 75 × 75, 100 × 100, 100 × 200, 200 × 100, 200 × 200, 200 × 300, 200 × 400, 300 × 300, and 400 × 400 mm VESA patterns.

For larger patterns, the included X-pattern adapter brackets are used to expand the mounting interface. Confirm the exact VESA specification in your TV manual before ordering.

Installation and Wall Requirements

The wall or mounting surface must support the combined weight of the mount and TV. Strong provides installation instructions for appropriate wood-stud and concrete mounting conditions.

For wood-stud installations, the manual specifies studs of at least 2" × 4" with no more than 3/8" drywall covering them. For concrete installations, the manufacturer provides separate requirements for concrete density, anchor placement, and drilling.

Do not mount the assembly to drywall alone. Strong also specifies a minimum of two people for attaching and positioning the display.

Cable Management and Access

Three installed cable clips help route power and signal cables along the articulating arm. Leave enough slack for the TV to move through its intended swivel, extension, and tilt range without pulling or pinching the cables.

If you are completing the rest of the TV setup, you can also browse power management solutions and soundbars.

What's Included?

• 1 wall arm assembly
• 4 X-pattern adapter brackets
• 1 installed adapter plate
• 1 installed wall plate cover kit
• 3 installed cable clips
• Mounting hardware kit
• Mounting template

The television, AV cables, electrical components, in-wall wiring, and any installation-specific hardware not supplied by Strong are sold separately.

When to Choose Another Mount

Choose another model if your TV exceeds 55", weighs more than 100 lb, uses a mounting pattern outside the supported VESA list, or needs the added stability and reach of a larger dual-arm articulating mount.

Complete Your TV Setup

• Compare TV Wall Mounts
• Shop Soundbars
• Power Management Solutions

Need Help Confirming Compatibility?

Send Bear Security Shop your exact TV model number and tell us what type of wall you are mounting it to. We can help you confirm the TV weight, VESA pattern, wall requirements, and whether the SM-CB-ART1-M is the right fit before you order.

Is the Strong SM-CB-ART1-M sold individually?

Yes. One SM-CB-ART1-M is a complete single-arm wall mount for one compatible TV. The package includes the arm assembly, adapter brackets, mounting hardware, cable clips, wall plate cover, and mounting template.

Is this a tilt mount or a full-motion mount?

It is a full-motion articulating mount. In addition to tilt, the arm extends away from the wall and swivels horizontally. Strong officially classifies the SM-CB-ART1-M as a single-arm articulating mount.

What TV sizes does it support?

Strong specifies a 24–55" display range with a maximum TV weight of 100 lb. Your TV must also use one of the supported VESA mounting patterns.

What VESA patterns are supported?

Strong lists 75 × 75, 100 × 100, 100 × 200, 200 × 100, 200 × 200, 200 × 300, 200 × 400, 300 × 300, and 400 × 400 mm. Always confirm the exact pattern in your TV specifications before ordering.

How far does the SM-CB-ART1-M extend?

Strong's current product specifications list up to 19" of extension and approximately 3.25" depth when retracted.

How much can the TV swivel and tilt?

The mount provides up to 180° swivel, +15°/-5° tilt, and ±5° roll adjustment. Actual usable swivel depends on TV width, wall placement, cables, and nearby surfaces.

What is the maximum supported TV weight?

The maximum load is 100 lb (45 kg). Do not exceed this rating even if your TV's screen size and VESA pattern otherwise fit the mount.

Can it be mounted directly to drywall?

No. The wall structure must safely support the combined mount and TV load. The manufacturer's instructions cover suitable wood-stud and concrete installations, not drywall alone.

Are the 400 × 400 adapter brackets included?

Yes. Four X-pattern adapter brackets are included and are used when required for larger supported VESA patterns.

Does it include cable management?

Yes. Three cable clips are installed on the arm assembly. Cables should still have enough slack to move safely as the TV extends, swivels, and tilts.

Is this mount weather rated for outdoor use?

The manufacturer documentation reviewed does not identify an outdoor weather rating for the SM-CB-ART1-M. It should not be treated as a weather-rated outdoor TV mount.

How many people are required for installation?

Strong specifies a minimum of two people for installation, particularly when attaching the display to the arm assembly.

What should I confirm before ordering?

Confirm the exact TV model, screen size, weight, VESA pattern, wall construction, rear-port clearance, and the amount of swivel and extension you need.
