Sonos Sub 4 Wireless Subwoofer Deep Bass Trueplay Tuned

Full-Size Sonos Bass for Home Theater and Music

Sonos Sub 4 SUBG4US1 is a full-size powered wireless subwoofer designed to add deeper low-frequency impact to compatible Sonos soundbars and speakers. Its dual inward-facing 5" × 8" elliptical woofers use a force-cancelling configuration to help reduce cabinet vibration while extending bass down to 25 Hz.

Sub 4 is especially well suited to premium living rooms, media rooms, and Sonos home theater systems where stronger low-frequency output is a priority.

Key Specifications

• Product type: Powered wireless subwoofer
• Woofers: 2 × 5" × 8" elliptical woofers
• Amplification: 2 built-in Class-D digital amplifiers
• Architecture: Ported cabinet
• Low-frequency extension: Down to 25 Hz
• Wireless: Wi-Fi 6 compatible, 2.4 GHz / 5 GHz
• Wired network: 10/100 Ethernet
• Room tuning: Trueplay with a compatible Sonos system
• Power: 100–240V AC, 50/60Hz
• Finish: Matte Black or White

Who Should Choose Sonos Sub 4?

Choose Sub 4 when you already have a compatible Sonos soundbar or amplified Sonos speaker and want substantially deeper bass than the main speaker can produce on its own.

Compared with Sub Mini, Sub 4 is the better fit when maximum compactness is less important and you want Sonos's larger, more powerful subwoofer platform for movies, TV, gaming, and music.

Dual 5-Inch × 8-Inch Force-Cancelling Woofers

Sub 4 uses two custom 5" × 8" elliptical woofers positioned inward toward each other. Their opposing movement creates a force-cancelling effect that helps reduce unwanted cabinet vibration and distortion.

Each woofer is driven by its own Class-D digital amplifier tuned to the subwoofer's acoustic architecture.

Bass Extension Down to 25 Hz

Sonos specifies low-frequency extension down to 25 Hz. The ported cabinet and built-in DSP work together with the paired Sonos product to balance bass response across the system.

Trueplay System Tuning

Trueplay measures the acoustics of the room and fine-tunes the Sonos system's EQ. Sonos lists Sub 4 Trueplay support with compatible iOS and Android devices.

Trueplay behavior depends on the Sonos product Sub 4 is paired with and the tuning method supported by that system.

Wi-Fi 6 and Ethernet

Sub 4 supports compatible 802.11a/b/g/n/ac/ax networks on 2.4 GHz and 5 GHz, including Wi-Fi 6.

A 10/100 Ethernet port is also available for a wired network connection when appropriate.

Wireless Audio, Wired Power

Sub 4 communicates with the Sonos system wirelessly over the network, so a traditional RCA subwoofer cable is not required.

Sub 4 is not battery powered. It requires a nearby AC outlet during use.

Compatible Sonos Systems

Sub 4 works with compatible amplified, non-portable Sonos products running the current Sonos app.

For home theater, Sonos currently supports Sub 4 with Sonos home theater products except Playbar and Playbase. It is not compatible with products such as Move, Roam, Port, Connect, or older unsupported speakers.

Browse Sonos products when planning or expanding a compatible system.

Flexible Placement

Sub 4 can stand upright, lie on its side, or be placed beneath suitable furniture where ventilation and clearance allow.

Its wireless audio connection allows more placement flexibility than a conventional subwoofer that requires a dedicated line-level cable back to the receiver or amplifier.

Dimensions and Weight

• Height: 15.31" (389 mm)
• Width: 15.83" (402 mm)
• Depth: 6.22" (158 mm)
• Weight: 25.99 lb (11.79 kg)
• Colors: Black or White
• Finish: Matte

What's Included?

• 1 Sonos Sub 4
• 6 ft power cable
• Setup guide
• Legal and warranty documentation

Complete Your Sonos Home Theater

• Sonos
• Soundbars
• Subwoofers

Need Help Checking Compatibility?

Send Bear Security Shop your Sonos soundbar or speaker model, room size, and current system. We can help confirm Sub 4 compatibility and whether Sub 4 or Sub Mini is the better fit.

How many woofers does Sonos Sub 4 use?

Sub 4 uses two inward-facing 5" × 8" elliptical woofers in a force-cancelling configuration.

How low does Sonos Sub 4 play?

Sonos specifies bass extension down to 25 Hz.

How many amplifiers are built in?

Sub 4 uses two Class-D digital amplifiers, one matched to each woofer.

Is Sonos Sub 4 wireless?

Audio and system communication can be wireless over Wi-Fi, so no RCA subwoofer cable is required. Sub 4 still requires continuous AC power.

Does Sub 4 support Wi-Fi 6?

Yes. Sub 4 supports compatible 802.11ax Wi-Fi 6 networks as well as earlier supported Wi-Fi standards on 2.4 GHz and 5 GHz.

Does Sub 4 have Ethernet?

Yes. It includes a 10/100 Ethernet port for an optional wired network connection.

Does Sub 4 support Trueplay?

Yes. Trueplay can tune the combined Sonos system for the room when Sub 4 is paired with a compatible Sonos product.

Does Sub 4 work with Sonos Arc Ultra?

Yes. Arc Ultra is compatible with Sub 4.

Does Sub 4 work with Sonos Beam?

Yes. Sonos currently lists Beam home theater products as compatible with Sub 4.

Does Sub 4 work with Sonos Ray?

Yes. Ray is a compatible Sonos home theater product.

Does Sub 4 work with Sonos Port?

No. Sonos Port cannot pair directly with Sub 4.

Does Sub 4 work with Sonos Move or Roam?

No. Sonos Move and Roam products cannot pair directly with Sub 4.

Can Sub 4 be placed on its side?

Yes. Sonos allows Sub 4 to stand upright or lie on its side.

What are the dimensions?

Sub 4 measures approximately 15.31" high × 15.83" wide × 6.22" deep and weighs 25.99 lb.
