Pure Resonance Audio MX9 Pro Rack Mixer 9-Channel Bluetooth DSP

Mix Microphones, Music, and More from One Rack-Mount Mixer

The Pure Resonance Audio MX9 is a 9-channel analog mixer designed for systems that need reliable control over microphones, music, and other audio sources. Its 3U rack-mount design combines seven microphone/line channels, additional stereo inputs, Bluetooth streaming, USB media functions, and a built-in 24-bit DSP effects processor.

It is a practical choice for houses of worship, schools, gyms, restaurants, conference rooms, event spaces, and other locations that need to mix several sources before sending audio to an external amplifier or powered speakers.

Key Specifications

• Product type: 9-channel analog rack-mount mixer
• Rack height: 3U
• Microphone inputs: 7 XLR inputs
• Line inputs: 7 × 1/4" TRS inputs, plus additional inputs on channels 8–9
• Channel inserts: 7 × 1/4" TRS
• Phantom power: Switchable +48V for channels 1–7
• Channel EQ: 3-band high, mid, and low EQ
• Effects: 24-bit DSP processor with 24 effect presets
• Media playback: Bluetooth and USB/MP3 media player
• Computer connection: USB sound-card function and computer recording
• Main outputs: Stereo XLR and 1/4" TRS
• Additional outputs: AUX, FX, and headphone monitoring
• Frequency response: 20Hz–20kHz, ±3dB

Who Should Choose the MX9?

Choose the MX9 when you need to combine several microphones with music or other audio sources and want hands-on control from a rack-mounted mixer. Its channel controls, monitoring functions, and built-in effects are useful for spoken announcements, presentations, live vocals, background music, and small events.

The MX9 is a mixer, not a power amplifier. For passive speakers, connect its output to a compatible audio amplifier. Powered speakers with suitable line-level inputs can connect to the mixer without a separate power amplifier.

Seven Microphone and Line Channels

Channels 1–7 each provide an XLR microphone input, a 1/4" TRS line input, and a 1/4" TRS insert. Switchable +48V phantom power supports compatible condenser microphones.

Additional inputs on channels 8–9 accommodate other mono or stereo sources. The MX9 also provides RCA tape inputs and recording connections, including additional front-panel tape inputs.

Three-Band EQ and Individual Channel Control

Each of the first seven channels provides individual gain, high/mid/low EQ, pan, pre-fader listening, peak indication, and a volume fader. These controls help balance voices and music before they reach the main output.

The mixer also provides a 75Hz high-pass filter for microphone inputs to help reduce unwanted low-frequency noise.

24-Bit DSP Effects

The onboard 24-bit DSP processor provides 24 effect presets, including reverb, delay, vocal echo, chorus, flanger, phaser, and pitch-change effects.

These are audio effects for shaping a mix. The MX9 should not be confused with a dedicated speaker-management DSP that provides independently configurable loudspeaker crossovers, delay, and room correction for multiple speaker zones.

Bluetooth, USB Playback, and Recording

The integrated media player includes a display and supports Bluetooth audio streaming from compatible devices, USB/MP3 playback, USB sound-card functionality, and USB computer recording.

Bluetooth provides a convenient music source alongside microphones or other connected inputs. It does not make the MX9 a wireless speaker or give it built-in amplification.

Flexible Outputs and Monitoring

Connect the MX9 to a compatible amplifier or powered-speaker system using its stereo XLR or 1/4" TRS main outputs. Separate AUX and FX outputs provide additional routing options, while the front-panel headphone connection supports monitoring.

Each channel also has a pre-fader listen (PFL) switch for checking its signal independently of the main mix.

3U Rack-Mount Design

The MX9 uses a standard 19" rack-width chassis and occupies 3U of rack space. Allow enough clearance for cable connections and ventilation when planning the equipment rack.

• Height: 5.51" (140 mm)
• Width: 19" (483 mm)
• Depth: 9.45" (240 mm)
• Weight: 8.82 lb (4 kg)
• Power supply: Built-in switching supply, 110–220V
• Power consumption: 23W or less

What's Included?

• 1 Pure Resonance Audio MX9 rack-mount mixer
• 1 power cord

Microphones, audio cables, amplifiers, and speakers are sold separately unless otherwise specified.

Complete Your Audio System

• Pure Resonance Audio
• Audio Amplifiers
• Audio Mixers & Signal Processors

Need Help Matching Your Mixer to Your Audio System?

Send Bear Security Shop your microphone count, music sources, speaker models, and amplifier details. We can help check the connections and determine whether the MX9 has the inputs and outputs your system needs.

Is the Pure Resonance Audio MX9 a powered mixer?

No. The MX9 is an audio mixer without a built-in speaker power amplifier. Passive speakers require a separate compatible amplifier.

How many microphone inputs does the MX9 have?

The MX9 provides seven XLR microphone inputs on channels 1–7. Additional inputs are available for other audio sources.

Does the MX9 provide phantom power?

Yes. Switchable +48V phantom power is available for compatible microphones on channels 1–7.

Can I play Bluetooth music while using microphones?

Yes. Bluetooth audio can be mixed with compatible connected microphone and line-level sources.

Can the MX9 play music from USB?

Yes. Its built-in media player supports USB/MP3 playback. It also supports USB sound-card functionality and computer recording.

What does the DSP processor do?

The MX9 includes a 24-bit DSP effects processor with 24 presets for effects such as reverb, delay, echo, chorus, and pitch change. It is not a dedicated multi-zone speaker-management DSP.

Does each microphone channel have EQ?

Yes. Channels 1–7 provide three-band EQ with individual gain, pan, monitoring, and volume controls.

What outputs does the MX9 have?

It includes stereo XLR and 1/4" TRS main outputs, AUX and FX outputs, and a headphone monitoring output.

How much rack space does the MX9 need?

The MX9 occupies 3U of rack space and measures approximately 19" wide × 5.51" high × 9.45" deep.

Can I connect the MX9 directly to 70V speakers?

No. The MX9 provides line-level audio outputs. A compatible 70V amplifier is required to power 70V speakers.

What is included in the box?

The manufacturer lists one MX9 mixer and one power cord. Microphones, signal cables, amplifiers, and speakers are separate.
