Episode ES-550T-SNDBR-50 Thin 3-Channel Passive Soundbar

True Left, Center, and Right Audio in a Thin TV-Friendly Design

The Episode ES-550T-SNDBR-50-BLK combines three independent passive speakers into one slim 48.92-inch cabinet, providing dedicated left, center, and right channels for TVs 55 inches and larger.

At only 1.83 inches deep, it keeps the front soundstage visually clean while delivering clearer dialogue and wider separation than built-in TV speakers.

Speaker and Amplifier Specifications

• Three independent left, center, and right channels
• Nominal impedance: 6 ohms per channel
• Recommended amplification: 20-100W RMS per channel
• Power handling: 100W RMS per channel
• Peak power handling: 250W
• Frequency response: 110 Hz-22 kHz
• Sensitivity: 88 dB at 2.83V/1m
• Crossover frequency: 2.5 kHz

The 250W specification is a peak rating, not continuous RMS power. Use an AV receiver or amplifier that is stable with a 6-ohm speaker load and appropriately matched to the soundbar.

Driver Design

• Four 4-inch anodized-aluminum cone woofers
• Three 1-inch titanium-dome tweeters with neodymium magnets and ferrofluid cooling
• Four 4-inch anodized-aluminum passive radiators

Because the soundbar reaches down to approximately 110 Hz, a powered subwoofer is recommended for deeper movie and music bass.

What You Need

This is a passive soundbar and does not connect directly to a TV for audio. It requires three amplified channels from an AV receiver or compatible amplifier and three runs of speaker wire.

It does not include HDMI ARC, eARC, optical audio, Bluetooth, Wi-Fi, streaming, or built-in amplification.

Mounting and Placement

• Wall mounting with the included wall plate
• Tabletop or cabinet placement with included kickstands
• TV-mount attachment using a separately sold compatible mounting accessory
• Integrated rear wire-management channel
• Hidden 1/2-inch IR receiver knockout behind the grille

When placed on furniture, keep the front of the soundbar close to the front edge of the cabinet and angle it toward the listening position.

Included

• One ES-550T-SNDBR-50-BLK passive soundbar
• Two adjustable kickstands
• Wall-mount plate
• Rubber feet
• Mounting hardware
• IR receiver spacer

Sold Separately

• AV receiver or three-channel amplifier
• Speaker wire
• Powered subwoofer
• Surround speakers
• IR receiver
• Optional TV-mount soundbar bracket

Dimensions and Finish

• 48.92 inches wide × 5.17 inches high × 1.83 inches deep
• Weight: 12.3 lb
• Black finish
• Acoustically transparent cloth grille
• Removable screw-down terminals accepting up to 14 AWG wire
• Limited lifetime manufacturer warranty

Need Help Confirming Compatibility?

Send Bear Security Shop your TV size, AV receiver model, speaker setup, and mounting method. We can help confirm amplifier compatibility, wiring, and whether this soundbar is the right size for your system.

Is the ES-550T-SNDBR-50-BLK powered?

No. It is a passive soundbar and requires three amplified channels for the left, center, and right speakers.

Is it sold individually?

Yes. One soundbar is included, containing all three independent LCR speaker channels.

What amplifier power is recommended?

Episode recommends 20-100W RMS per channel with a 6-ohm load.

Can it connect directly to a TV?

No. It does not include HDMI ARC, eARC, optical, Bluetooth, Wi-Fi, or built-in amplification. The TV normally connects to an AV receiver, which powers the soundbar.

Does it need three speaker-wire connections?

Yes. The left, center, and right channels are electrically independent and require three separate speaker-wire runs.

Does it include a subwoofer?

No. A powered subwoofer is sold separately and is recommended for deeper bass below the soundbar's 110 Hz frequency range.

What mounting hardware is included?

A wall-mount plate, adjustable kickstands, rubber feet, mounting hardware, and an IR receiver spacer are included. A bracket for attaching the soundbar directly to a TV mount is optional.

What are the dimensions?

It measures 48.92 inches wide × 5.17 inches high × 1.83 inches deep and weighs 12.3 lb.

Can it be used outdoors?

No. This soundbar is intended for dry indoor locations and has no outdoor weather rating.

What should I confirm before ordering?

Confirm your TV width, receiver's 6-ohm compatibility, available left-center-right amplifier channels, speaker-wire routing, and preferred mounting method.
